Core Practical 9: Continuous Monitoring of Rates of Reaction

Aim: To measure how the rate of reaction changes with different concentrations of hydrochloric acid (HCl) by collecting the hydrogen gas (H₂) produced during its reaction with magnesium (Mg), and to use this data to calculate the rate of reaction over time.

Chemical Equation

Mg(s) + 2HCl(aq) → MgCl₂(aq) + H₂(g)

Apparatus and Chemicals

Apparatus

Chemicals

Method

Experimental setup showing magnesium reacting with hydrochloric acid and hydrogen gas collected in a gas syringe.
  1. Setup: Assemble the gas syringe or inverted measuring cylinder and secure with clamps.
  2. Initial Reaction: Add 50 cm³ of HCl of known concentration to the conical flask. Add the magnesium ribbon, insert the bung quickly, and start the stopwatch immediately.
  3. Data Collection: Record the volume of hydrogen gas collected every 15 seconds for at least 2.5 minutes, or until the reaction stops.
  4. Repeat: Carry out the experiment with other HCl concentrations (0.25, 0.5, and 1.0 mol dm⁻³).

Example Data Table

Time (s) Volume of H2 (cm3) at 1.0 mol dm−3
00
1525
3041
4553
6060
7565
9067
10568
12068

Analysis and Calculations

Plotting Results: Plot a graph of volume of H₂ vs time. The gradient gives the rate of reaction.

Initial Rate

Rate of reaction graph showing tangent at t = 0 s to determine initial rate.

Draw a tangent at time = 0 s.
Initial Rate = ΔVolume / ΔTime

Comparative Analysis

Graphs showing how order of reaction with respect to concentration can be identified.

Sample Initial Rate Calculation

From graph: At 1.0 mol dm⁻³, 25 cm³ of gas is produced in 15 seconds.
Rate = 25 cm³ ÷ 15 s = 1.67 cm³ s⁻¹

Sources of Error

Improvements
