Ligand Substitution Reactions

Specification Reference Inorganic chemistry, Transition metals 3.2.5.2

Quick Notes

  • H2O, NH3, and Cl− are monodentate ligands — they can donate a single pair of electrons to a central metal ion to form a co-ordinate bond.
    • NH3 and H2O are similar in size and uncharged, so ligand exchange between them does not change the co-ordination number or charge of the complex.
    • Cl− is larger than H2O and NH3, so substitution of H2O by Cl− often leads to a change in co-ordination number from 6 to 4.
  • Ligands can also be bidentate (form two co-ordinate bonds) (e.g., H2NCH2CH2NH2, C2O42−) or multidentate (form more than two co-ordinate bonds) (e.g., EDTA4−).
  • The chelate effect describes how bidentate or multidentate ligands tend to replace monodentate ligands due to an increase in entropy.
  • Haem is an iron(II), Fe2+ complex with a multidentate ligand and oxygen (O2) can form a co-ordinate bond to the Fe(II) in haemoglobin, enabling it to be transported in the blood.
  • Carbon monoxide (CO) is toxic because it binds more strongly to the iron(II) in haemoglobin than oxygen, preventing oxygen transport.

Full Notes

Ligands in a complex ion can sometimes be substituted for different ligands in what are called ligand substitution or ligand exchange reactions.

Monodentate Ligands (H2O, NH3, and Cl−)

Monodentate ligands can donate one lone pair to the central metal ion.

For Example: Common examples include H2O (aqua), NH3 (ammine) and Cl− (chloride)

AQA A-Level Chemistry examples of monodentate ligands H2O, NH3, and Cl−

NH3 and H2O are similar in size and uncharged, and usually six molecules of each can fit around a central ion in a complex, getting close enough to form co-ordinate bonds to it.

This gives the complex a co-ordination number of 6 and an octahedral shape.

AQA A-Level Chemistry shapes of complexes with H2O or NH3 (octahedral, CN = 6) and with Cl− (tetrahedral, CN = 4)

Chloride ions, Cl−, are larger than H2O and NH3, and only four Cl− ligands can fit around a central ion, giving the complex a co-ordination number of 4 and a tetrahedral shape.

Substitution of H2O by NH3

Only six H2O or NH3 ligands can get close enough to a metal ion to co-ordinately bond to it.

As a result, if ligand substitution occurs and H2O ligands are substituted or exchanged for NH3 ligands, there is no change in co-ordination number (stays 6).

For Example Cu2+ complex with NH3:

[Cu(H2O)6]2+ + 4NH3 ⇌ [Cu(NH3)4(H2O)2]2+ + 4H2O

Colour change: Blue → Deep Blue.

Substitution is incomplete (only 4 NH3 molecules replace H2O) however co-ordination number remains 6.

Substitution of H2O by Cl−

Chloride (Cl−) ligands are larger than H2O, so the co-ordination number decreases (from 6 to 4) if substitution occurs.

This is because only four Cl− ligands can get close enough to the central metal ion to co-ordinately bond to it.

For Example Cu2+ complex with Cl-:

[Cu(H2O)6]2+ + 4Cl− ⇌ [CuCl4]2− + 6H2O

Colour change: Blue → Yellow and co-ordination number changes from 6 to 4.

Bidentate and Multidentate Ligands

Bidentate ligands form two co-ordinate bonds.

For Example
Ethyl-1,2-diamine (H2NCH2CH2NH2) and ethanedioate (C2O42−) .

AQA A-Level Chemistry examples of bidentate ligands such as ethane-1,2-diamine and ethanedioate

Multidentate ligands form multiple co-ordinate bonds.

For Example
EDTA4− (forms 6 co-ordinate bonds, replacing all H2O ligands).

AQA A-Level Chemistry diagram of multidentate ligand EDTA4− showing multiple donor sites

The Chelate Effect

There is a tendency for bidentate or multidentate ligands to replace monodentate ligands in complexes.

This is driven by an increase in entropy and is called the Chelate Effect.

For Example: Reaction of [Cu(H2O)6]2+ with C2O42− ions

AQA A-Level Chemistry chelation example forming [Cu(C2O4)3]4− from [Cu(H2O)6]2+ and ethanedioate (C2O4^2-) ions

Entropy increases (+ΔS) as the number of free particles increases (4 reactant particles compared to 7 product particles). ΔG is more negative, making the reaction more feasible.

Haemoglobin and Oxygen Transport

Haemoglobin in red blood cells contains Fe2+ bound to a multidentate ligand (haem). O2 binds to Fe2+ via a co-ordinate bond, allowing oxygen transport in the blood. Caron Monoxide (CO) is toxic because it binds more strongly to the Fe2+ than O2.

AQA A-Level Chemistry schematic of haem group showing Fe2+ centre and multidentate ligand environment

This binding of CO instead of O2 decreases the ability of blood to transport oxygen:

AQA A-Level Chemistry comparison of O2 vs CO binding to the Fe2+ centre in haemoglobin
