Energy Profiles and Transition States in Multistep Reactions HL Only

Specification Reference R2.2.7

Quick Notes:

  • Energy profiles show energy changes as reactants turn into products.
  • Multistep reactions have multiple peaks and valleys:
    • Each peak = a transition state
    • Each valley = an intermediate
  • The highest peak = rate-determining step (RDS).
  • Activation energy (Ea) is the energy difference between reactants and the peak of the step.
  • Profiles help link kinetic data (reaction rate) to the mechanism.

Full Notes:

For an introduction to energy profiles and the basics, please see here.

In reactions that occur in multiple steps, the energy profile helps visualize the activation energies and transition states for each elementary step.

Key Features of Multistep Energy Profiles

IB Chemistry energy profile diagram showing multiple peaks for transition states and valleys for intermediates in a multistep reaction.

Rate-Determining Step (RDS)

The tallest peak corresponds to the step with the highest activation energy (Ea).

IB Chemistry reaction energy profile with multiple steps, showing the tallest peak as the rate-determining step.

See here for more detail.

Summary
