Molecular Polarity and Dipole Moments

Specification Reference S2.2.6

Quick Notes

  • A molecule is polar if it has a net dipole moment.
  • Molecular polarity depends on the polarity of individual bonds and the shape (geometry) of the molecule.
  • Even if a molecule has polar bonds, the dipoles may cancel depending on geometry.
  • Non-polar molecules:
    • No polar bonds present
    • Or molecule has a symmetrical shape where bond dipoles cancel
  • Polar molecules:
    • Asymmetric shape
    • Or dipoles that don’t cancel

Full Notes

What Determines Molecular Polarity?

A molecule can be polar or non-polar, depending on whether it contains polar bonds and the molecule’s symmetry.

Non-polar molecules have no permanent dipole

If polar bonds are arranged symmetrically, dipoles cancel out and the molecule is non-polar.

IB Chemistry diagram showing non-polar molecules with symmetrical bond dipoles cancelling out.

Example: CO2

Each C=O bond is polar, but the molecule is linear, so dipoles cancel. No overall dipole = non-polar molecule.

Example: CCl4 (Tetrachloromethane)

Each C–Cl bond is polar, but tetrahedral shape means dipoles cancel. CCl4 is non-polar despite having polar bonds.

Polar molecules have a permanent dipole

If dipoles do not cancel due to asymmetry, the molecule is polar.

IB Chemistry diagram showing polar molecules with asymmetric shapes where dipoles do not cancel.

Example: H2O

O–H bonds are polar and form a bent shape (104.5°). Dipoles do not cancel meaning water is polar.

Example: CHCl3 (Chloroform)

The C–H and C–Cl bonds have different polarities. Dipoles do not cancel meaning CHCl3 is polar.

How to Deduce Molecular Polarity

Deciding whether a molecule is polar or non-polar can be difficult – even if it contains polar bonds!

Follow this method:

Summary
